Case IH Vestrum 120 vs Case IH Vestrum 130

Choose up to three tractors and compare engine, drivetrain, PTO, hydraulics, dimensions, and operator equipment in one clear view.

Overview

At a glance

The Case IH Vestrum 120 and Vestrum 130 are two utility tractors from the same Vestrum family, built on a similar platform but tuned for different power needs. Both share the FPT NEF 4.5L turbocharged diesel engine, closed-center load-sensing hydraulics, and a broadly similar operator environment — so on paper they look like siblings. The real differences show up in output, drivetrain sophistication, and how much muscle they can put to work in the field. This comparison is useful for buyers deciding between the two trims, particularly farmers weighing whether the extra power and lifting capacity of the 130 justifies stepping up from the 120.

Key differences

What separates them

Power and torque — The 130 is the clear winner here. It puts out 130 HP (up to 140 HP on overboost) versus the 120’s 118.4 HP gross rating. More telling is the torque: the 130 delivers 630 Nm at 1300 RPM with a healthy 41% torque rise, giving it noticeably better lugging power under load — useful for heavy tillage or PTO-intensive work. The 120’s torque figures aren’t officially listed, which itself suggests it’s positioned as the lighter-duty option.

Transmission — Both offer a Powershift and CVXDrive CVT option, but the 130 specifically names an “ActiveDrive 8 Powershift,” implying a more refined shifting setup. Functionally they’re close, though the 130’s drivetrain feels like the more developed version.

Hydraulics and lift capacity — This is where the gap widens the most. The 130 offers 5,600 kg of rear lift capacity compared to just 4,199 kg on the 120 — a difference that matters a lot if you’re running heavy implements like large disc harrows or loaded trailers. The 130 also adds a couple of extra auxiliary valves (4 rear + 2 mid vs. 4 rear + 3 mid optional on the 120, though the two spec sheets aren’t fully consistent here).

Tyres and stability — The 130 rides on larger tyres (420/70R24 front, 520/70R42 rear) versus the 120’s 380/85R24 front and 460/85R34 rear. Bigger rubber generally means better traction and a higher load rating, which lines up with the 130’s higher max permissible weight (10,000 kg vs. ~7,250 kg for the 120).

Size and weight — Despite sharing the same unladen weight (5,850 kg), the 130 is physically larger — about 700mm longer overall (4,784 mm vs. ~4,060 mm) and slightly taller, which tracks with its heavier-duty billing.

Comfort and electronics — Both get air suspension seats and adjustable steering columns, but the 130 leans more modern with its AFS Pro 700+ display and MultiControl armrest, suggesting a more premium cab experience aimed at operators spending long hours in the seat.

Bottom line — The Vestrum 120 suits lighter mixed-use farms where fuel efficiency and a lower price point matter more than raw grunt. The Vestrum 130 is the better pick if you’re regularly running heavier implements, need more lift capacity, or want a more feature-rich cab — essentially the same tractor family, but built for a step up in workload.

Your comparison
SIDE-BY-SIDE DATA

Specification comparison

A dash means that the field has not been entered for that tractor.

FieldCase IHCase IH Vestrum 120Case IHCase IH Vestrum 130
BrandCase IHCase IH
CategoryTractorTractor
General Identification
BrandCase IH (CNH Industrial)Case IH
Model NameVestrum 120Vestrum 130
Model Year2023Not specified
SeriesVestrum SeriesVestrum Series
ConfigurationAgriculturalAgricultural
Tractor ClassUtility TractorUtility Tractor
Drive Configuration4WD4WD
Engine
Engine ManufacturerFPT (Fiat Powertrain Technologies)FPT Industrial
Engine ModelNEF 4.5LNEF / F28
Engine TypeDiesel, 4‑Cylinder TurbochargedDiesel, Inline Turbocharged
Number of Cylinders44
Bore × StrokeNot specifiedNot specified
Engine Displacement4.5 L (4500 cc)4500 cc
Compression RatioNot specifiedNot specified
AspirationTurbocharged with IntercoolerTurbocharged with intercooler
Fuel SystemCommon Rail Direct InjectionCommon Rail Direct Injection
Injection PumpHigh Pressure Common RailHigh Pressure Common Rail
Rated Engine Speed2200 RPM2200 RPM
Maximum Engine Power118.4 HP (gross) / 128.2 HP (max)130 HP @ 2200 RPM (max 140 HP)
Maximum TorqueNot specified (~500 Nm estimated for class)630 Nm @ 1300 RPM
Torque RiseNot specified41%
Governing TypeElectronicElectronic
Cooling FanViscous DrivenEngine Driven, viscous
Air Intake SystemDry Air CleanerDry air cleaner
Exhaust OrientationVertical with HI‑eSCR2Vertical
Emission StandardT4B / Stage V (SCR + DEF)EU Stage V / Tier 4 Final (Hi‑eSCR2)
Power Output
Engine Gross Power118.4 HP130 HP
PTO Power102 HP111 HP
Drawbar Power~85–90 HP~90–100 HP (estimated)
Hydraulic Power Loss~5–10%~10–12%
Brake System
Brake TypeHydraulic Wet DiscHydraulic wet disc
ActuationHydraulicIndependent hydraulic
Parking BrakeIndependent Electro‑HydraulicIndependent mechanical
Brake CoolingOil ImmersedOil bath
PTO (Power Take-Off)
PTO TypeIndependentIndependent electro‑hydraulic
PTO EngagementElectro‑Hydraulic Wet DiscElectro‑hydraulic wet disc
PTO Speed540 / 540E / 1000 RPM540 / 540E / 1000 RPM
PTO Shaft1‑3/8" 6‑Spline / 21‑Spline1‑3/8" 6‑Spline / 21‑Spline
PTO DirectionClockwiseClockwise
Ground Speed PTONoOptional
Hydraulic System
Hydraulic TypeClosed Center Load‑SensingClosed center load sensing
Hydraulic PumpVariable DisplacementAxial piston variable displacement
Max Hydraulic Pressure~200 bar200 bar
Lifting Capacity4199 kg5600 kg rear
Lift ControlElectronic Lower‑Link Draft SensingEDC electronic draft + position
3-Point HitchYesYes
Hitch CategoryII / III N OptionalCategory 2
Lower Link EndsBall Type / Quick HitchBall type
Auxiliary Valve4 Rear / 3 Mid Optional4 rear + 2 mid
Response ControlElectronic / ProportionalProportional electrical
Fuel, Fluids & Capacities
Fuel Tank180 L180 L
Engine Oil~12 L~12 L
Transmission Oil~50 L~50 L
Hydraulic OilShared ReservoirShared with transmission
Coolant~20 L~20 L
Transmission & Drivetrain
Clutch TypeElectro‑Hydraulic Wet DiscWet Multi‑Disc
Clutch DiameterNot specifiedNot specified
Transmission TypePowershift / CVTActiveDrive 8 Powershift / CVXDrive CVT
Gearbox Configuration24‑speed Powershift / CVXDrive CVT24F × 24R
Forward Gears24 / Infinite24
Reverse Gears24 / Infinite24
Forward Speed Range0–40 km/h (50 km/h optional)Up to 40 km/h
Reverse Speed RangeSimilar to forwardUp to 40 km/h
Final DriveInboard PlanetaryInboard planetary
Differential LockElectro‑Hydraulic Rear StandardElectro‑hydraulic
Tyres & Axle Data
Tyre TypeRadial R1WAgricultural R1W
Front Tyres380/85R24420/70R24
Rear Tyres460/85R34520/70R42
Front AxleHeavy Duty 4WDClass 1.75 suspended (optional)
Rear AxlePlanetaryFlange half shaft
Track Width (Front)AdjustableAdjustable
Track Width (Rear)AdjustableAdjustable
Electrical & Electronics
Electrical System12V Negative Ground12V
Battery CapacityNot specifiedNot specified
Alternator Output200A120A+ (estimated)
Starter MotorElectricElectric
Instrument ClusterDigital / AFS CompatibleDigital / AFS Pro 700+
Warning IndicatorsComprehensive (AFS, DEF etc.)Oil, temperature, charging, DEF
Steering System
Steering TypeHydrostatic / Power SteeringHydrostatic Power Steering
Steering GearLoad SensingLoad sensing
Turning Radius (with brakes)~5.0 m~4.5 m (estimated)
Steering ColumnAdjustable / Tilt‑TelescopingTilt & telescopic adjustable
Operator Environment
SeatAir Suspension PremiumAir suspension premium
Suspension SeatStandardYes
ROPSCab StandardIntegrated cab
CanopyNo (Cab Only)Not specified
FootstepIntegrated PlatformsAnti‑slip
Control LayoutErgonomic Right ConsoleMultiControl armrest
Implement Compatibility Matrix
MB PloughYesYes
Disc HarrowYesYes
CultivatorYesYes
Rotavator (5–6 ft)YesYes
ThresherYesYes
BalerYesYes
Trailer (Hydraulic)YesYes
Dimensions & Weight
Wheelbase2490 mm2492 mm
Overall Length~4060 mm4784 mm
Overall Height~2920 mm~3200 mm
Overall Width~2410 mm~2400 mm
Minimum Ground Clearance~460 mm~500 mm
Unladen Weight5850 kg5850 kg
Max Permissible Weight~7250 kg~10000 kg
